Compact 60kW Urban Dispenser Single Outlet 200A Retail Parking IP54 Weatherproof Enclosure

Most urban sites do not need a 480kW cabinet, but they do need a real DC fast charge rather than an AC top up. The Bailu series 60kW configuration delivers 200A from a single gun in the same 756 x 706 x 1908mm cabinet, which fits a retail car park bay, a hotel forecourt or a service station corner without a separate plant room. The unit runs on three phase 5 wire input, AC380V ±15%, with a power factor of 0.99, so it can share an existing low voltage supply.

• 60kW compact configuration - single gun at 200A maximum, 100A balanced output, sized for urban top up and opportunity charging.
• Same 756 x 706 x 1908mm cabinet as the rest of the series - one bay footprint, one spare parts kit, one operator workflow across power classes.
• CCS1, CCS2, CHAdeMO and GB/T compatible DC gun - imported and domestic EVs use the same charging bay.
• DC200V-1000V output window - covers 400V passenger EVs and 800V platforms without a second model.
• Three phase 5 wire input, AC380V ±15%, 50Hz/60Hz, power factor 0.99 - suitable for retail and commercial low voltage supplies.
• 10 inch high brightness colour touch screen - clear tariff and session display, readable in direct sunlight.
• Six start methods - QR code, card, VIN recognition, RFID, APP and CMS remote start, so staffed and unattended sites share the same hardware.
• OCPP1.6J over 4G, Ethernet, WiFi and APP - joins an existing CMS or payment platform without custom integration work.
• IP54, air cooled, -40℃ to +60℃ - outdoor installation without a shelter, including coastal and cold climate sites.
• Six layer electrical protection - short circuit, over temperature, over current, earth leakage, over voltage and under voltage protection.
• TUV, CE and FCC certified, OEM and ODM available - housing colour, logo, language pack and tariff logic can be customised.

A 60kW unit is the lowest cost way to put a genuine DC fast charge into a location with limited grid capacity. It suits sites where drivers park for 30 to 60 minutes, so the vehicle gains a useful range while the driver shops, eats or works. Sites that need to serve long distance traffic at short stops should step up to 120kW or above within the same family.

Retail and supermarket car parks, hotel and restaurant forecourts, office and commercial plazas, service stations, car wash and workshop yards, and small fleet depots. Locations with 30 to 60 minute dwell time and a limited low voltage supply.

The 5 metre cable as standard covers most retail bay layouts, including nose in and reverse parking. Because the cabinet is air cooled and rated IP54, no additional enclosure is required for an outdoor bay, and the operating range of -40℃ to +60℃ covers cold storage yards and hot coastal car parks. Tell us your bay layout and expected sessions per day, and our team will confirm the power class and cable routing.
