3500W Mobile EV Charger Portable Power Station 3072WH LiFePO4 Battery 16S4P

All Category

3500W Mobile EV Charger Portable Power Station 3072WH LiFePO4 Battery 16S4P

Brand Name:	CHENMAI
Model Number:	CM-MES-3500
MOQ:	1 Piece
Packaging Details:	Wooden crate with shock-proof foam insert, export-grade packaging
Payment Terms:	T/T,L/C,PayPal,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Luoyang, Henan, China

Certification:

CE, RoHS, UN38.3

Rated Output Power:

3500W

Peak Output Power:

7000W

Output Waveform:

Pure Sine Wave (ripple Below 200mV)

Battery Type:

32140 Cylindrical LiFePO4

Battery Capacity:

3072WH (16S4P)

Cycle Life:

2000 Cycles, Capacity Retained Over 75%

Inverter Efficiency:

Up To 95%

Charge Efficiency:

Max Charge Current:

15A Constant Current

Charge Time:

4 Hours To 90%, 1 Hour To Full Top-up

Cooling Fan Start:

Heatsink Protection:

85C High-temperature Trigger

Over-Temperature Protection:

Battery Above 65C, MOS Above 95C

AC Input:

186-236V, 220V/50-60Hz

Net Weight:

Dimensions:

466 X 230 X 550mm

Supply Ability:

3000 Pieces per Month

Highlight:

3500W Mobile EV Charger

Portable Power Station 3072WH

LiFePO4 Battery 16S4P

Product Description

The 3500W Mobile EV Charger is a portable energy storage power station engineered for reliable off-grid and emergency EV charging. Combining a high-power pure sine wave inverter, a long-life LiFePO4 battery pack and efficient fast charging, it delivers dependable power wherever you need it.

Key Features

High-Power Inverter Output: Rated 3500W, peak 7000W, pure sine wave output with ripple below 200mV, suitable for a wide range of loads. Built-in short-circuit and overload protection with automatic power derating after overload.
Long-Cycle LiFePO4 Battery: 32140 cylindrical LiFePO4 cells retain over 75% capacity after 2000 cycles. 3072WH large capacity in a 16S4P configuration, protected by BMS hardware and software dual protection.
Efficient Charging and Discharging: Inverter conversion efficiency up to 95%, battery charging efficiency 92%. Supports max 15A constant-current charging, reaching 90% in 4 hours and full charge in 1 hour of top-up.
Intelligent Temperature Control: Cooling fan starts at 45C, heatsink triggers high-temperature protection at 85C, with multi-layer over-temperature protection for battery above 65C and MOS above 95C to keep the unit running stably.
Lid-Open Lighting: Opening the lid automatically lights a 5mm white LED with a lifespan over 100,000 hours, ideal for outdoor inspection and night use.
Wide Voltage Adaptability: AC input 186-236V, 220V/50-60Hz, maintaining high working efficiency under both high and low input voltages.
Compact and Portable: Net weight 39kg, dimensions 466 x 230 x 550mm, packed in a wooden crate for easy transport.

As a manufacturer and exporter, we support OEM and bulk orders. Contact us for wholesale pricing and customization.
