600kW Modular Energy Storage Charging System with Expandable Liquid-Cooled Terminals

All Category

600kW Modular Energy Storage Charging System with Expandable Liquid-Cooled Terminals

Brand Name:	Mckee Charging Cube
Model Number:	CLF-FDC 600KW
MOQ:	1
Price:	Negotiate
Packaging Details:	Wooden case packaging
Payment Terms:	L/C,D/A,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

LuoYang China

Certification:

Highlight:

600kW modular energy storage system

expandable liquid-cooled charging system

AC EV charger with energy storage

Product Description

600kW Split Energy Storage & Charging System, No Complete Equipment Replacement for Station Expansion

product description:

Conventional high-power chargers require full equipment renovation for expansion, bringing high renovation costs and long construction cycles. Our 600kW energy storage & charging system adopts split modular flexible charging stacks with exclusive phased expansion design. Only liquid-cooled terminals need to be added for extra charging bays, while the original power units can be fully reused. Centralized power supply via a shared unified power pool eliminates redundant transformers and greatly cuts upfront power distribution investment. It is perfectly suited for phased expansion of heavy-truck charging stations at highways and logistics parks, effectively reducing initial capital pressure.

Detail Information:

Place of Origin:

Luoyang, China

Certification:

CE

Power Level:

480/600/800/960/1440kW

Exportable Routes:

Maximum 16 Channels

Input Voltage:

327-456Vac

Output Voltage Range:

DC50*1000V

Output Current Range:

Whole Machine 0-2400A

Efficiency:

Peak Efficiency ≥95.5%

Power Factor:

≥0.99

Protection Level:

IP55

Highlight: commercial EV charger floor mounted,
outdoor DC charging station 600KW,
group charging station electric

advantage:

The maximum output power of a single gun is 600 kW. Charging for 3 minutes, the endurance is 200km
Use 40 kW Si℃ module. Peak efficiency ≥97%, module allocation pre-granularity is 40 kW. 11 parking spaces are shared
960kW power pool
600A liquid cooling terminal meets 2015+/ChaOji compatible with future charging needs

600kW Modular Energy Storage Charging System with Expandable Liquid-Cooled Terminals 0

600kW Modular Energy Storage Charging System with Expandable Liquid-Cooled Terminals 1

600kW Modular Energy Storage Charging System with Expandable Liquid-Cooled Terminals 2

About McKee

Mckee is a manufacturer focusing on electric car charging stations and related electric car accessories. Committed to sustainable development since 2011, we constantly aim to adopt clean and green technologies, striving to provide safe and green energy services through technological innovation.

We provide complete electric vehicle charging solutions, from innovative energy storage technology to public DC fast charging stations, fast charging stations and portable charging stations for home use. Our infrastructure can meet every type of demand.

Frequently Asked Questions

How long is your delivery time?

For charging posts, it is usually 3-10 days. If there is no stock, the production lead time is determined according to the order quantity. High-power DC charging posts usually need to be customized according to the customer's technical parameters.

How long does it take to customize the prototype?

For charging piles, the prototype time is usually 7 days. For DC charging posts, the prototype time is usually 15 days. For high power fast charging stations, the technical parameters need to be determined before production, and the prototype time is usually 30 days.

How to guarantee the service?

Our products are divided into two categories: household and commercial. For home chargers, we provide standardized service: 1 year warranty + remote installation and usage guidance + video installation tutorial. For commercial chargers, we provide both standardized services and payment software docking services for operating companies.

How do you guarantee the quality of your products?

The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are in progress.

Additional Information: OEM supported. Any requirement please contact us to talk about the details. We will reply to your inquiry within 24 hours. The above for reference only, final price determined by charger KW - please contact us for accurate quote.
