DC Fast Charging Station Electric Charging Pile Electric Charging Station With RFID 4g Commercial

All Category

DC Fast Charging Station Electric Charging Pile Electric Charging Station With RFID 4g Commercial

Brand Name:	Mckee Charging Cube
Model Number:	CLF-DC-120KW
MOQ:	1
Price:	Negotiate
Packaging Details:	Wooden case packaging
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Luoyang, China

Certification:

CE/UL/CHAdeMO

Prophylactic:

Temperature Protection

Charging Time:

20-40 Mins (10-80%)

Rated Power:

DC 120kW

Input Voltage:

480 VAC

Output Voltage:

220-1000V DC Constant

Output Power:

120KW

Charging Interface:

CCS2/CCS1/CHAdeMO

Protection Level:

Warranty:

24 Months

Certifed:

CE/UL/CHAdeMO

RFID System:

OCPP1.6,WIFI,3/4G，pose

Charging Cable Length:

Highlight:

Commercial Use Electric Charging Pile

4g Electric Charging Pile

RFID Electric Charging Pile

Product Description

DC fast charging station electric charging pile electric charging station with RFID 4g commercial use

✔ Fast Charging Speed – Suitable for most EVs, delivers ~80% charge in 20-40 mins (varies by battery size).
✔ Dual-Port Flexibility – Often supports CCS + CHAdeMO or dual CCS connectors.
✔ Cost-Effective – Lower installation and operational costs vs. ultra-rapid chargers.
✔ Wide Compatibility – Works with most EVs (except some high-voltage models).

Technical Parameters:

Parameter	Specification
Power Output	120kW (max)
Voltage Range	200-1000V DC
Current Output	Up to 300A
Connector Types	CCS1/CCS2, CHAdeMO (optional)
Efficiency	≥93%
Cooling System	Liquid-cooled cables (optional)
Grid Compatibility	3-phase AC, 380-480V
Dimensions	~800x600x1800mm (varies by model)
Weight	300-500kg

Type	Power Range	Charging Time (Example)	Use Case
120kW	DC Fast	30–40 mins (80%)	Public fast-charging
7kW–22kW	AC Slow	6–10 hours (100%)	Home/workplace
350kW+	Ultra-Fast	15–20 mins (80%)	Premium charging hubs

Best For:

Highway rest stops
Urban fast-charging hubs
Fleet operators
